  • MPQ4230GVE-0000-AEC1-Z

  • MPQ4230GVE-0000-AEC1-Z

    The MPQ4230 is a buck-boost converter with four integrated power switches. The device can deliver up to 5A of output current within a certain input-supply range with excellent load and line regulation.

    The MPQ4230 is designed for USB power delivery (USB PD) application. It can work well with external USB PD controller through an I2C interface. The I2C interface and MTP (2-time programmable) provide flexibility of configurable features.

    Fault condition protections include CC current limiting, output OVP, and thermal shutdown (TSD). The MPQ4230 requires a minimal number of readily available, standard external components. The MPQ4230 is available in a QFN-21 (4mmx5mm) package.


    • 0.00
      0.00
商品描述

The MPQ4230 is a buck-boost converter with four integrated power switches. The device can deliver up to 5A of output current within a certain input-supply range with excellent load and line regulation.

The MPQ4230 is designed for USB power delivery (USB PD) application. It can work well with external USB PD controller through an I2C interface. The I2C interface and MTP (2-time programmable) provide flexibility of configurable features.

Fault condition protections include CC current limiting, output OVP, and thermal shutdown (TSD). The MPQ4230 requires a minimal number of readily available, standard external components. The MPQ4230 is available in a QFN-21 (4mmx5mm) package.


Features & Benefits

  • Supports 60W Buck-Boost or 5A Peak IOUT

  • Wide 4V to 36V Operating Input Voltage Range

  • 3.6V to 20.5V Output Voltage Range, 10mV resolution

  • 250kHz, 350kHz, and 420kHz Frequency Selectable or SYNC Input

  • Frequency Spread Spectrum Selectable

  • Line Drop Compensation

  • Accurate CC Output Current Limit

  • I2C Interface and 2-Times Programmable MTP (PMBus Compatible):

  • -   PFM/PWM Mode, Current Limit, Output Voltage, Frequency Spread Spectrum, Line Drop Comp, etc.

  • -   CRC Check for MTP Integrity

  • Battery Short-to-Ground Protection Driver

  • Load-Shedding Alert

  • EN Shutdown Active Discharge

  • Available in a QFN-21 (4mmx5mm) Package with Wettable Flanks

  • Available in AEC-Q100 Grade
