  • MPQ2013AGQ-AEC1-Z

  • MPQ2013AGQ-AEC1-Z

    DESCRIPTION
    The MPQ2013A is a low power linear regulator
    that supplies power to systems with high
    voltage batteries. It includes a wide 2.5V to 40V
    input range, low dropout voltage and low
    quiescent supply current. The low quiescent
    current and low dropout voltage allow
    operations at extremely low power levels.
    Therefore, the MPQ2013A are ideal for the low
    power microcontrollers and the battery-powered
    equipments.
    The MPQ2013A provides wide variety of fixed
    output voltage options (if request): 1.8V, 1.9V,
    2.3V, 2.5V, 3.0V, 3.3V, 3.45V, 5.0V; and also
    provides the output adjustable option (from
    1.215V to 15V).
    The regulator output current is internally limited
    and the device is protected against over-load
    and over-temperature conditions.
    The MPQ2013A also includes thermal
    shutdown and current limiting fault protection,
    and is available in QFN-6 (2mmx2mm), and
    QFN-8 (3mmx3mm) packages.

    • 0.00
      0.00
商品描述

DESCRIPTION
The MPQ2013A is a low power linear regulator
that supplies power to systems with high
voltage batteries. It includes a wide 2.5V to 40V
input range, low dropout voltage and low
quiescent supply current. The low quiescent
current and low dropout voltage allow
operations at extremely low power levels.
Therefore, the MPQ2013A are ideal for the low
power microcontrollers and the battery-powered
equipments.
The MPQ2013A provides wide variety of fixed
output voltage options (if request): 1.8V, 1.9V,
2.3V, 2.5V, 3.0V, 3.3V, 3.45V, 5.0V; and also
provides the output adjustable option (from
1.215V to 15V).
The regulator output current is internally limited
and the device is protected against over-load
and over-temperature conditions.
The MPQ2013A also includes thermal
shutdown and current limiting fault protection,
and is available in QFN-6 (2mmx2mm), and
QFN-8 (3mmx3mm) packages.

FEATURES  2.5V to 40V Input Range  3.3µA Quiescent Supply Current  Stable With Low-value Output Ceramic Capacitor (> 0.47 μF)  150mA Specified Current for QFN-6 and QFN-8 Packages  620mV Dropout at 150mA Load  Available in Fixed and Adjustable Output (1.215 V to 15 V) Versions  Output ±2% Accuracy for QFN-8 Package Output ±4% Accuracy for QFN-6 Package  Specified Current Limit  Thermal Shutdown  -40°C to +150°C Specified Junction Temperature Range  Available in QFN-6 (2mmx2mm), or QFN-8 (3mmx3mm) Packages  Available in AEC-Q100 Grade 1 APPLICATIONS  Industrial/Automotive Applications  Portable/Battery-Powered Equipment  Ultra low power Microcontrollers  Cellular Handsets  Medical Imaging
